Patella Mesh Locking Plate is designed for the fixation of patellar fractures, especially comminuted and multi-fragmentary types. Its mesh-style architecture allows maximum bone coverage while permitting soft tissue integration, promoting biological healing and stable fixation.
This plate is compatible with 2.7mm Locking Screws, offering rigid and secure fixation with minimal prominence. It can be cut or contoured intraoperatively based on the patient’s patellar anatomy, making it ideal for tailored surgical solutions.
🔧 Technical Features & Specifications:
- Material: Medical-grade stainless steel
- Application: Fixation of transverse, stellate, and comminuted patellar fractures
- Screw Compatibility: 2.7mm Locking Screws
- Plate Design: Mesh configuration with low-profile structure
- Hole Configuration: 16 uniformly spaced screw holes
- Thickness: 1.0mm
🏥 Clinical Applications:
- Comminuted patellar fractures
- Transverse or stellate patellar injuries
- Multiple fragment reconstructions
- High-energy trauma to the anterior knee
✅ Key Benefits:
- Mesh Design: Allows flexible contouring and soft tissue passage
- Low Profile: Minimizes soft tissue irritation and hardware prominence
- Multi-Hole Pattern: Permits variable screw positioning for optimal fixation
📏 Available Variants:
| Code | Size | Holes | Thickness (mm) | Width (mm) | Length (mm) |
|---|---|---|---|---|---|
| 5100-3401 | Small | 16 | 1.0 | 30 | 38 |
| 5100-3402 | Medium | 16 | 1.0 | 33 | 42 |
| 5100-3403 | Large | 16 | 1.0 | 36 | 46 |
🏷️ Manufactured by Strength Industries
- Leading provider of trauma implants
- CE & ISO certified surgical solutions
- Trusted by hospitals and orthopedic surgeons worldwide
