Proximal Femoral Hook Locking Plate with Cable is an advanced orthopedic implant designed for stable fixation of complex proximal femur fractures, particularly in osteoporotic or comminuted bones. This plate combines the mechanical benefits of locking screw technology with an integrated cable system to provide enhanced fixation in high-stress regions of the femur.
Its low-profile, hook-type design ensures optimal grip over the greater trochanter and proximal shaft, offering superior biomechanical stability and reduced risk of implant failure. The incorporated cable slots allow the surgeon to pass 1.7mm cerclage cables, increasing the construct’s resistance against rotational and axial forces.
The implant is compatible with 5.0mm Locking Screws, 4.5mm Cortical Screws, and 1.7mm Surgical Cable, allowing for tailored fixation strategies to match specific fracture types.
🔧 Technical Features & Specifications:
- Material: Medical-grade stainless steel
- Screw Compatibility: 5.0mm Locking, 4.5mm Cortical Screws
- Cable Compatibility: 1.7mm Cerclage Cable
- Plate Design: Anatomically contoured with hook-end and cable holes
- Application Side: Available in Left and Right configurations
- Width: 17.5mm
- Thickness: 6.2mm
🏥 Clinical Applications:
- Fixation of proximal femoral fractures (intertrochanteric, subtrochanteric)
- Greater trochanteric fractures with displacement
- Complex femur fractures in osteoporotic patients
- Periprosthetic femur fracture treatment
✅ Advantages & Benefits:
- Integrated Cable Slots: Allow passage of cerclage wire for enhanced fixation
- Hook Design: Offers superior purchase on the greater trochanter
- Locking Plate Stability: Helps prevent screw loosening in osteoporotic bone
- Side-Specific Designs: Precise anatomic contour for left and right femur
- Enhanced Versatility: Can be used in trauma and reconstructive surgeries
📏 Available Variants:
| Side | Holes | Thickness (mm) | Width (mm) | Length (mm) |
|---|---|---|---|---|
| Left | 4 | 6.2 | 17.5 | 233 |
| Left | 6 | 6.2 | 17.5 | 258 |
| Left | 8 | 6.2 | 17.5 | 283 |
| Left | 10 | 6.2 | 17.5 | 308 |
| Left | 12 | 6.2 | 17.5 | 333 |
| Right | 4 | 6.2 | 17.5 | 233 |
| Right | 6 | 6.2 | 17.5 | 258 |
| Right | 8 | 6.2 | 17.5 | 283 |
| Right | 10 | 6.2 | 17.5 | 308 |
| Right | 12 | 6.2 | 17.5 | 333 |
🌍 Why Choose Our Hook Locking Plates with Cable?
- Combination Fixation: Provides screw and cable-based stability
- Perfect for Osteoporotic Bone: Prevents implant loosening and migration
- Trusted in Complex Surgeries: Used worldwide for revision and trauma cases
- Comprehensive Size Range: Multiple hole options for varied fracture patterns
