Proximal Femoral Locking Plate-I is designed for the fixation of complex fractures of the proximal femur, including intertrochanteric, subtrochanteric, and high femoral shaft fractures. Anatomically contoured to match the proximal femoral anatomy, this plate ensures optimal fit, improved load distribution, and precise angular stability. The design allows polyaxial locking capability, promoting secure fixation in osteoporotic or comminuted bone conditions. This plate is used with 5.0 mm locking screws and 4.5 mm cortical screws depending on anatomical region and stability requirements.
Manufactured by Strength Industries – ISO 13485, CE, and FDA certified.
Technical Specifications
| Holes | Side | Thickness (mm) | Width (mm) | Length (mm) |
|---|---|---|---|---|
| 5 | Left | 6.0 | 18 | 153 |
| 7 | Left | 6.0 | 18 | 189 |
| 9 | Left | 6.0 | 18 | 225 |
| 11 | Left | 6.0 | 18 | 261 |
| 13 | Left | 6.0 | 18 | 297 |
| 5 | Right | 6.0 | 18 | 153 |
| 7 | Right | 6.0 | 18 | 189 |
| 9 | Right | 6.0 | 18 | 225 |
| 11 | Right | 6.0 | 18 | 261 |
| 13 | Right | 6.0 | 18 | 297 |
Clinical Applications
- Proximal femoral shaft fractures
- Subtrochanteric femur fractures
- Comminuted proximal femur injuries
- Reconstruction after tumor resection or deformity correction
- Osteoporotic bone fixation requiring angular stability
Key Features
- Anatomical contour for optimal fit with proximal femur
- Angular stable fixation using locking screws
- Low-profile design minimizes soft tissue irritation
- Biocompatible stainless steel or titanium options
- Multiple length and side options (Left/Right)
- Compatible with 5.0 mm locking & 4.5 mm cortical screws
