Straight Reconstruction Locking Plate is engineered for precision fracture management and complex reconstruction procedures. Crafted from high-quality surgical-grade stainless steel, this plate offers excellent strength, durability, and compatibility with 3.5mm Locking Screws and 3.5mm Cortical Screws.
With a thickness of 3.2mm and a sleek anatomical design, it is ideal for stabilizing long bone fractures and providing rigid fixation in orthopedic reconstructions. Its straight profile ensures versatility in multiple applications, especially where straight-line access and alignment are needed.
🔧 Technical Features & Specifications:
- Material: Surgical Stainless Steel
- Screw Compatibility: 3.5mm Locking & 3.5mm Cortical Screws
- Plate Thickness: 3.2mm
- Plate Width: 11mm
- Surface Finish: Smooth-polished
- Design: Straight profile, multi-hole reconstruction structure
🏥 Clinical Applications:
- Stabilization of long bone fractures
- Complex reconstructions in orthopedic trauma
- Corrective osteotomies
- Fixation of fractures in anatomically challenging locations
✅ Advantages & Benefits:
- Versatile Straight Design: Suitable for a wide range of reconstructions
- Locking & Cortical Screw Compatible: Offers dual-mode fixation
- Low-Profile & Durable: Minimizes soft tissue interference
- Premium Stainless Steel: Provides high strength and corrosion resistance
- Multiple Hole Variants: Customizable to fracture complexity
📏 Available Sizes:
| Holes | Thickness (mm) | Width (mm) | Length (mm) |
|---|---|---|---|
| 5 | 3.2 | 11 | 66 |
| 6 | 3.2 | 11 | 79 |
| 7 | 3.2 | 11 | 92 |
| 8 | 3.2 | 11 | 105 |
| 9 | 3.2 | 11 | 118 |
| 10 | 3.2 | 11 | 131 |
| 12 | 3.2 | 11 | 157 |
🌍 Why Choose Us?
- Surgeon-Optimized Design for faster and secure procedures
- Precision Engineering using ISO & CE-certified processes
- Durability & Biocompatibility from high-grade materials
- Global Reach with products trusted worldwide
